Otu esi agbakọ ike Shaft achọrọ maka mgbapụta turbine kwụ ọtọ miri emi
1. Usoro mgbako ike mgbapụta mgbapụta
Ọnụego mgbaba × isi × 9.81 × ọkara nke ike ndọda ÷ 3600 ÷ arụmọrụ mgbapụta
Nkeji na-efe efe: cubic/ hour,
Nkeji ebuli: mita
P=2.73HQ/η,
N'ime ha, H bụ isi na m, Q bụ ọnụego eruba na m3 / h, na η bụ arụmọrụ nkemiri emi ọma vetikal turbine mgbapụta. P bụ ike aro na KW. Ya bụ, ike aro nke mgbapụta P = ρgQH / 1000η (kw), ebe ρ = 1000Kg / m3, g = 9.8
Akụkụ nke ike ndọda kpọmkwem bụ Kg/m3, unit nke eruba bụ m3 / h, unit nke isi bụ m, 1Kg=9.8 Newtons.
Mgbe ahụ P=kpọnyere ike ndọda* na-asọ * isi*9.8 Newton/Kg
=Kg/m3*m3/h*m*9.8 Newton/Kg
=9.8 Newton*m/3600 sekọnd
=Newton*m/367 sekọnd
= Watts/367
Mwepụta nke dị n'elu bụ mmalite nke unit ahụ. Usoro dị n'elu bụ ngụkọta nke ike mmiri. A na-ekewa ike osisi site na arụmọrụ.
Were ya na ike aro bụ Ne, ike moto bụ P, na K bụ ọnụọgụ (ntụgharị nke arụmọrụ)
Ike moto P = Ne * K (K nwere ụkpụrụ dị iche iche mgbe Ne dị iche, lee okpokoro n'okpuru)
Ne≤22 K=1.25
iri abụọ na abụọ
55
2. Mgbakọ usoro nke slurry mgbapụta aro ike
Ọnụego mgbaba Q M3/H
Ebuli H m H2O
Ịrụ ọrụ n %
Njupụta nke Slurry A KG/M3
Shaft ike N KW
N=H*Q*A*g/(n*3600)
Ike moto chọkwara ka elele arụmọrụ nnyefe yana ihe nchekwa. N'ozuzu, a na-ewere njikọ kpọmkwem dị ka 1, a na-ewere eriri dị ka 0.96, na ihe nchekwa bụ 1.2.
3. Ịrụ mgbapụta mgbapụta na usoro nhazi ya
Na-ezo aka na oke nke ike dị irè nke miri emi ọma vetikal turbine mgbapụta ka aro ike. η=Pe/P
Ike nke mgbapụta na-ezokarị aka na ike ntinye, ya bụ, ike a na-ebufe site na onye na-ebugharị ya na ogwe mgbapụta, ya mere a na-akpọkwa ya ike ogwe ma na-anọchi anya P.
Ikike dị irè bụ: ngwaahịa nke isi mgbapụta ahụ, oke ọsọ ọsọ na ike ndọda.
Pe=ρg QH (W) ma ọ bụ Pe=γQH/1000 (KW)
ρ: Njupụta nke mmiri mmiri na-ebufe site na mgbapụta (kg / m3)
γ: Ike ike mmiri mmiri nke mgbapụta ahụ na-ebu γ=ρg (N/m3)
g: osooso n'ihi ike ndọda (m/s)
Ọnụego mgbaba oke Qm=ρQ (t/h ma ọ bụ kg/s)
4. Okwu Mmalite nke Ịrụ Ọrụ Pumps
Kedu ihe bụ arụmọrụ mgbapụta? Gịnị bụ usoro?
Azịza: Ọ na-ezo aka na oke nke ike dị irè nke mgbapụta na ike ogwe. η=Pe/P
Ike nke olulu mmiri miri emi mgbapụta turbine kwụ ọtọ na-ezokarị aka na ike ntinye, ya bụ, ike a na-ebufe site na onye na-ebufe isi na ogwe mgbapụta, ya mere a na-akpọkwa ya ike ogwe ma na-anọchi anya P.
Ikike dị irè bụ: ngwaahịa nke isi mgbapụta ahụ, oke ọsọ ọsọ na ike ndọda.
Pe=ρg QH W ma ọ bụ Pe=γQH/1000 (KW)
ρ: Njupụta nke mmiri mmiri na-ebufe site na mgbapụta (kg / m3)
γ: Ike ike mmiri mmiri nke mgbapụta ahụ na-ebu γ=ρg (N/m3)
g: osooso n'ihi ike ndọda (m/s)
Mass eruba Qm=ρQ t/h ma ọ bụ kg/s
